Kessaku Mizu Tower Duplex

Rajajinagar, BangaloreDuplex L26-L27 sq ftUltra-LuxurySmart Home

Project Scope & Solutions

Premium Control & Interface Systems

Comprehensive wall-mounted control infrastructure with premium German design keypads throughout the duplex. Interactive LCD control panels in key areas. Central touchscreen dashboards for unified home management. iPad docking stations for mobile control. RF wireless remotes for convenient operation. Location-aware automation using beacon technology for intelligent scene activation.

Intelligent Sensing & Detection

Advanced occupancy sensing throughout the residence enabling automatic presence detection in all rooms. Photo sensors for daylight harvesting and adaptive lighting. Automatic lights on/off based on presence. Energy-saving when rooms are unoccupied. Daylight responsive dimming for comfort and efficiency. Customizable timeout settings for each zone.

Biometric Access Control & Security

Entry-level biometric readers at main entry points with fingerprint access for family members. Premium finger scanners at interior access points. Keyless entry doors with digital smart locks. High-resolution IP camera surveillance throughout. Multi-level security zones with integration to the automation system. Remote monitoring capability with comprehensive audit trail logging.

Advanced Lighting Control

DALI lighting protocol integration for precise dimming control. Multi-channel dimming modules throughout the residence. Scene-based lighting control with one-touch ambiance settings. Automated daylight integration and scheduling. Occupancy-based automation with smooth dimming transitions. Complete coverage across both levels of the duplex.

Video Distribution System

Network AV distribution enabling any source to any display throughout the residence. 4K video distribution with matrix switching capability. Stream content to multiple locations simultaneously. Fully integrated with entertainment system for seamless operation.

Premium Invisible Audio System

Completely concealed premium speakers with invisible architectural technology. Edge-mounted invisible speakers throughout living spaces. Premium in-ceiling architectural speakers in key areas. High-performance specialty speakers for enhanced audio zones. Audiophile-quality sound without any visual intrusion.

Meridian Reference Audio

Central audio processing hub with reference-grade active speakers. Digital signal processors for room-specific audio optimization. Deep bass response with dedicated subwoofers. Audiophile-grade sound quality with lossless audio distribution. Integrated bass management and room acoustic optimization.

Entertainment & Media Systems

Centralized movie server providing Blu-ray quality 4K movies on demand with lossless audio soundtracks. Multiple 4K movie players distributed across rooms. Movie library management with multi-room synchronized playback. Artwork and metadata display for an immersive experience. Motorized TV lifts and advanced display positioning systems.

Enterprise Network Infrastructure

Enterprise-grade WiFi with seamless roaming throughout the duplex. Centralized WiFi management with high-speed connectivity in all rooms. Guest network isolation for security. Professional equipment housing in dedicated racks. Managed network switching with enterprise-grade security. Full IoT device support for future expansion.

Project Highlights

Dual-Level Integration: Seamless automation across L26 and L27

Invisible Audio: Amina speakers deliver premium sound without visual intrusion

Reference-Grade Sound: Meridian audiophile systems throughout

Biometric Security: Fingerprint access at all entry and interior points

Kaleidescape Cinema: 4K movie library with lossless audio

Enterprise WiFi: Ruckus commercial-grade coverage

Location-Aware: Crestron Pinpoint beacons for intelligent automation

Premium Brands: Crestron, Meridian, Amina, Kaleidescape, Ekey, Yale, Mobotix

Engineering Blueprint

Detailed Technical Specifications

Control & Interface

Wall Keypads

Jung LS Automation 24V

Keypad Interfaces

Crestron C2N-UNI8IO

Designer Keypads

Basalte Keypad 204-04

LCD Keypads

Crestron C2N-LCDB3

Touchscreens

Crestron TSW-1060-W-S 10"

iPad Docking

iPort Launchport 70710

Sensing & Automation

Occupancy Sensors

Crestron GLS-OIRLCL-C-CN

Photo Sensors

Crestron GLS-LCL

Location Beacons

Crestron Pinpoint PP-100-W

Wireless Remotes

Crestron TSR-302-B

RF Gateway

Crestron CEN-GWEXER

Central Processor

Crestron with Bacnet

Security & Access Control

Entry Biometric

Ekey Integra

Interior Biometric

Ekey Arte Finger Scanners

Control Panels

Ekey CTL48 with Relay

Smart Locks

Yale Digital YDR 414

IP Cameras

Mobotix V25

Features

Audit Trails, Remote Monitor

Lighting & Digital Control

DALI Controllers

Crestron DIN-DALI2

Dimmer Modules

Crestron DIN-1DIM4

Switch Modules

Crestron DIN-8SW8

Inrush Modules

Crestron CLXI-4HSW4

Power Supplies

Crestron DIN-PWS60

Scenes

Morning, Evening, Away, Night

Audio Systems

Invisible Speakers

Amina IQ2 / Edge 5 / Edge 7

Ceiling Speakers

James Speaker 32 AT4

Specialty Speakers

Agath T222 / T232

Audio Matrix

Crestron SWAMPI-24x8

Distribution

24 Sources, 8+ Zones

Cabling

Profigold OFC Premium

Meridian Audio

Core Processing

Meridian Audiocore

Active Speakers

Meridian M6 Reference

DSP Processors

Meridian DSP 320

Subwoofers

Meridian Deep Bass

Controller

Meridian G65

Quality

Lossless Distribution

Video Distribution

NVX Encoders

Crestron DM-NVX-351C

Card Chassis

Crestron NVX

Director

Crestron DM-XIO-DIR-80

Resolution

4K Matrix Switching

Distribution

16 Points

HDMI

Crestron Premium Cables

Entertainment

Movie Server

Kaleidescape

Movie Players

Kaleidescape K0217-0000

Player Count

7 Rooms

Quality

Blu-ray 4K + Lossless

TV Automation

Future Automation

Display Mount

Future Automation SPS1300

Network Infrastructure

WiFi Access Points

Ruckus Zoneflex R510

WiFi Controller

Ruckus Zone Director

Network Switches

Managed Enterprise

Equipment Racks

42U Professional

Patch Panels

R&M Swiss Quality

Coverage

Full Duplex Seamless

Technical Accuracy Guaranteed

Certified by Fulcro Technical Execution Framework

Automation Scenes

morning Scene

Gradual lighting wake-up
Automated curtain opening
Climate adjustment
Morning news on displays
Gentle audio fade-in

evening Scene

Ambient lighting activation
Entertainment system ready
Climate optimization
Security system armed

away Scene

All lights off except security
Climate energy-saving mode
Security cameras active
Simulated occupancy lighting

entertainment Scene

Theater lighting scenes
Audio system activation
Display positioning
Optimal acoustic settings

night Scene

Pathway lighting
All systems standby
Security active
Climate night settings

Room Coverage

lower Level

Master Bedroom 1 (MBR1) with ensuiteBedroom 2 (BR2) with ensuiteBedroom 3 (BR3) with ensuiteLiving RoomPowder RoomLobbyDeck 1Deck 2

upper Level

Master Bedroom 2 (MBR2) with ensuiteArt Room with ensuiteFamily AreaAdditional spaces

Client Benefits

Ultimate Convenience

One-touch control of entire home with automated daily routines and mobile app access from anywhere.

Entertainment Excellence

Cinema-quality movie experience with audiophile sound throughout and invisible speaker aesthetics.

Enhanced Security

Biometric access control, video surveillance, remote monitoring, and automated security modes.

Energy Efficiency

Occupancy-based automation, daylight harvesting, optimized climate control, and smart scheduling.

Property Value

State-of-the-art smart home technology with premium brand components and future-proof infrastructure.

Project Impact

"The Kessaku Mizu Tower Duplex is a masterpiece of integrated technology. Our execution of the Crestron backbone, paired with reference-grade Meridian audio and invisible speaker technology, demonstrates how sophisticated automation can be woven into the fabric of a luxury duplex without compromising its architectural aesthetic."
